GWM series vortex mill is a kind of powder processing equipment advanced level, the company is the introduction of Germany advanced powder machine technology, through assimilate innovation from the development. Advanced structural principles of the machine, the world's most advanced mechanism - ultrasonic grinding and spray function, resulting in high-frequency vibration, continuous work, with simultaneous drying and pulverizing the dual function. The machine is a suitable inorganic, organic crushed generic special pulverizer solved at room temperature for ultra-fine grinding of special materials, polyvinyl alcohol, PVC, PE, fibrous materials and metal magnesium etc. Almost all heat-sensitive materials can be low melting point ultrafine grinding. Widely used in deep processing chemicals, dyes, plastics, plant fiber, herbs, non-metallic minerals, food and other industries crushing, product size up to 3 ~ 5mm.
Model
Parameter\ |
GWM-80
|
GWM-120
|
| Power£¨kw£© |
Rotor disc
|
55-90 |
110-160 |
Feeding device
|
1.1 |
1.1 |
Rotate speed r/min
|
Rotor disc
|
2000 |
1500 |
Feeding device
|
20-150 |
| Fineness£¨um£© |
5-400 |
| Evaporability kgh2o/h |
¡¡200-230 |
400-1000 |
| Grinding Index |
1 |
4 |
| Energy kg/h |
¡¡80-2500 |
120-5000 |
| Dimension L¡ÁW¡ÁH |
¡¡2500¡Á1200¡Á1550 |
3400¡Á1600¡Á2030 |
| Net Weight£¨kg£© |
3000 |
7000
|
